4 Best Flatbed Trailers for Hot Shot Hauling

1. MAXX-D GSB10240: 40' Single-Wheel Straight Deck

The GSB10240 has a flat 40-foot deck on single-wheel axles, which makes it the lightweight workhorse of the group. With no dovetail breaking up the surface, the entire deck stays usable for pallets, steel, pipe, lumber, and light machinery loaded by forklift or crane.

Its 12,000 lb GVWR keeps the trailer non-CDL behind a heavy-duty pickup, and a low 7,520 lb empty weight leaves more of that rating for cargo. Single-wheel axles also tow lighter and use less fuel on long runs than a tandem-dual setup. Eight-foot slide-in ramps ride on the trailer for the occasional rolling load, though the straight deck earns its keep with long, flat freight.

Owner-operators who want maximum deck length at the lightest weight class tend to start here. The GVWR can be uprated to 14K or 16K at purchase if your loads grow.

Key specs:

• Size: 40' long x 102" wide, single-wheel flatbed

• GVWR: 12,000 lbs (up-rate to 14K or 16K)

• Empty weight: 7,520 lbs; payload roughly 4,480 lbs

• Axles: two 8K electric brake axles, slipper spring suspension

• Ramps: 8' slide-in, no dovetail

• Coupler: 2-5/16" 30K round gooseneck; two 10K drop-leg jacks

• Storage: front neck toolbox plus a 48" side-mount toolbox

The MAXX-D GSB10240 offers a full 40-foot straight deck and 12,000 lb GVWR for non-CDL hot shot hauling.

2. MAXX-D GSX10240: 40' Non-CDL Gooseneck with MAXX Ramps

The GSX10240 has the same 40-foot single-wheel platform as the GSB10240, but splits it into 35 feet of flat deck plus a 5-foot dovetail with MAXX Ramps. That is the combination most hot shot operators are actually looking for, because it puts drive-on loading on a trailer that still stays non-CDL at 14,000 lb GVWR.

Empty weight is 8,280 lbs, leaving roughly 5,720 lbs of payload, around 1,240 lbs more than the GSB carries at its base rating. Mowers, compact tractors, and lighter wheeled equipment load over the ramps without a forklift or crane on site, and the hot shot riser box with chain rack keeps binders and chains off the deck.

Drivers who mix palletized freight with the occasional rolling load tend to land here rather than on the straight deck.

Key specs:

• Size: 40' long x 102" wide (35' flat plus 5' dovetail), single-wheel flatbed

• GVWR: 14,000 lbs (configurable to 12K or 16K)

• Empty weight: 8,280 lbs; payload roughly 5,720 lbs

• Axles: two 8K electric brake axles, slipper spring suspension

• Frame: 12" x 14lb I-beam with torque tube, 6" channel outer frame

• Coupler: 2-5/16" 30K round gooseneck; two 10K drop-leg jacks

• Storage: front neck toolbox, hot shot riser box with chain rack, 48" side-mount toolbox

The MAXX-D GSX10240 pairs a 35-foot flat deck with a 5-foot dovetail and MAXX Ramps for easy drive-on loading.

3. MAXX-D LKX10230: 30' Flatbed with 5' Dovetail

The LKX10230 sits between the other two on length at 30 feet, pairing a 25-foot flat deck with a 5-foot dovetail and full-width MAXX-D-OUT ramps. Tandem dual axles and a 25,990 lb GVWR give it far more capacity than the single-wheel GSB, so it carries skid steers, mini excavators, and dense mixed loads that would overrun a lighter trailer.

The dovetail and high-clearance ramps let wheeled and tracked equipment drive straight on without dragging, and a winch plate in the neck is ready for a self-recovery setup. A heavier 12" x 19lb I-beam frame and two 12K electric brake axles keep it stable under near-limit loads at highway speed.

Hot shot drivers who load equipment by ramp rather than by forklift get the most out of this build. At 25.9K GVWR, it runs in CDL territory for most tow vehicles, so confirm your rating and state rules before buying.

Key specs:

• Size: 30' long x 102" wide (25' flat plus 5' dovetail)

• GVWR: 25,990 lbs; payload roughly 17,090 lbs

• Axles: two 12K electric-brake axles, slipper spring suspension

• Wheels: tandem dual ST235/85R16 E-range tires

• Deck: 5' dovetail with MAXXD-OUT ramps, winch plate in neck

• Frame: 12" x 19lb I-beam with torque tube

• Coupler: 2-5/16" 30K round gooseneck; two 10K drop-leg jacks

The MAXX-D LKX10230 pairs a 25-foot flat deck with a 5-foot dovetail and 25,990 lb GVWR for heavy equipment hauling.

4. MAXX-D LDX10225: 25' Low-Pro Deckover

The LDX10225 is the shortest of the four and carries the highest listed payload, trading deck length for full-width capacity. At 25 feet with a 25,000 lb GVWR, it delivers an estimated 17,805 lbs of payload in a frame short enough to maneuver on tight job sites.

A low-profile deckover puts the deck over the wheels for a full 102 inches of usable width and a lower loading angle, which helps with wide or low-clearance freight. That extra width also lets you run pallets or crates side by side without the wheel wells cutting in. Two 10K electric brake axles and HDSS heavy-duty suspension hold it steady on long expedited hauls.

The payload handles a mid-size excavator right at capacity, or several compact machines per trip. Because it runs at 25K, confirm CDL requirements against your tow vehicle and state rules before you buy.

Key specs:

• Size: 25' long x 102" wide, low-pro tandem dual deckover

• GVWR: 25,000 lbs; payload roughly 17,805 lbs

• Axles: two 10K electric brake axles, HDSS heavy-duty slipper spring suspension

• Deck: 5' dovetail with MAXXD-OUT ramps

• Coupler: 2-5/16" 30K round gooseneck; two 10K drop-leg jacks

• Storage: front neck toolbox plus a 48" side-mount toolbox

The MAXX-D LDX10225 pairs a 25-foot low-pro deckover frame with an estimated 17,805 lbs of payload capacity.

Hot Shot Flatbed Comparison by Size & Capacity

Buying Your Hot Shot Flatbed From Poplar Bluff Trailer

The four options listed suit different kinds of hot shot work, from long, light freight on a straight deck to heavy equipment on a tandem-dual build. Once you know the load you run most, matching it to the right deck style and weight class is straightforward.

We make the rest just as simple. Our MAXX-D flatbeds sit on the Poplar Bluff, Missouri lot with inventory updated daily, so what you see online is what is actually available. Before you commit, our sales team confirms your GVWR needs and walks through any de-rate or up-rate options; once you decide, you can complete financing online in a few minutes. From there, you can choose free in-store pickup or book paid delivery to most of the Midwest. Check our live inventory to confirm the build that fits your work before driving out.

Frequently Asked Questions (FAQs)

What size flatbed is best for hot shot hauling?

Most hot shot operators run a 40-foot gooseneck flatbed, since it maximizes deck length while staying under CDL weight limits at a 12K or 14K GVWR. Drivers hauling heavier, denser freight instead choose a shorter 25- to 30-foot trailer with a higher axle rating, trading length for payload capacity.

Do I need a CDL to run a hot shot flatbed?

It depends on your combined gross weight rating. Flatbeds rated at 12K or 14K GVWR, paired with a one-ton pickup, usually keep you under the 26,001-pound federal CDL threshold. Higher-rated trailers near 25K can push a combination over that line, so confirm your rating against state rules.

What is a dovetail, and does a hot shot trailer need one?

A dovetail is the angled rear section of a deck that lowers the ramp angle for loading rolling equipment. Hot shot drivers hauling skid steers, mowers, or wheeled machines benefit from a dovetail with full-width ramps. Those carrying only pallets, steel, or lumber loaded by forklift can run a flat straight deck instead.

Can a hot shot flatbed haul cars and equipment too?

Yes. A gooseneck flatbed handles vehicles, machinery, building materials, and palletized freight on the same deck, which is why expeditors who mix load types favor it. A dovetail with ramps makes drive-on loading easier, while a straight deck keeps a flat, uninterrupted surface for crane or forklift loading.

Where can I buy a hot shot flatbed trailer near me in Missouri or Illinois?

Poplar Bluff Trailer stocks hot shot flatbeds at its Poplar Bluff, Missouri lot and serves buyers across Missouri, Illinois, and the Mid-South, including St. Louis, Cape Girardeau, and Memphis. We update inventory daily, provide online financing, and offer free in-store pickup plus paid delivery, with most customers buying within one to five days.



*Note: Prices shown are estimates based on current market conditions at the time of writing and may change without notice. Confirm trailer availability, specifications, and final pricing directly with Poplar Bluff Trailer.
