3 Best Gooseneck Trailers for Backhoes: Specs, Length & GVWR

Key Takeaways

• A standard backhoe weighs between 14,000 and 18,000 lbs, so any gooseneck trailer used to haul one needs a minimum GVWR of 25,000 lbs to stay legal and keep a usable safety margin.

• Deck length matters as much as GVWR, and while 32 feet is the practical minimum for most backhoes, machines with wide stances or long rear overhangs need 36 or 40 feet to sit correctly over the axles.

• The MAXX-D LDB10232 and LDX10236 at Poplar Bluff Trailer run Electric Over Hydraulic disc brakes, which deliver more consistent stopping force than standard electric brakes under heavy loads and wet conditions.

• The MAXX-D LKX10240 at Poplar Bluff Trailer gives larger backhoes 35 feet of flat deck, a built-in WARRIOR 18K Winch for loading disabled machines, and a hydraulic package with wireless remote for solo operation.

• Poplar Bluff Trailer stocks all three MAXX-D gooseneck trailers with daily inventory updates, so you can check live availability before making the trip.

Which Gooseneck Trailers Are Best for Backhoes?

Three MAXX-D gooseneck trailers are built for backhoe hauling: the 32-foot LDB10232, the 36-foot LDX10236, and the 40-foot LKX10240. All three carry a GVWR of 25,000 lbs or more, with the LDB10232 and LDX10236 running EOH disc brakes and the LKX10240 running electric brake axles, together covering the payload and stopping power a loaded backhoe demands on public roads.

Each targets a different use case, from tight urban job sites to larger machines with wide stances or long tail swings. Poplar Bluff Trailer stocks all three, and the breakdown below covers what sets each trailer apart so you can match the right one to your machine.

Top 3 Gooseneck Trailers for Backhoes

MAXX-D is one of the most reputable gooseneck trailer brands.

1. MAXX-D LDB10232 102" x 32' Gooseneck Flatbed (Best for Tight Jobsite Access)

The MAXX-D LDB10232 is a heavy-duty engineered beam flatbed built for operators who need serious hauling capability in a manageable footprint. It's the most maneuverable of the three options here, making it a smart pick for urban job sites or areas with limited turning radius.

Key Specs

• Model: LDB Engineered Beam Flatbed

• Frame: Heavy Duty Steel Frame with I-Beam Neck

• Brakes: Electric Over Hydraulic (EOH) Disc Brakes

• Coupler: 2-5/16" 30K Round Gooseneck Coupler

• Jacks: 2 x JOST 2-Speed Jacks

• Ramps: MAXXD-OUT Ramps (Full Width Coverage)

• Dovetail: 5' Dovetail

• Floor: 2x8 Treated Wood Floor

• Storage: Front Tool Box in Neck

Length

At 32 feet total (27' flat deck plus 5' dovetail) and 102 inches wide, the LDB10232 fits a standard backhoe comfortably without adding unnecessary trailer length. The full-width MAXXD-OUT ramps make loading straightforward even on machines with limited ground clearance.

GVWR and Payload

The LDB10232 carries a GVWR of 25,900 lbs with a payload of roughly 16,960 lbs, with an optional 30,000 lb GVWR rating available. EOH disc brakes deliver faster, more consistent stopping than standard electric brakes at this weight class.

2. MAXX-D LDX10236 36' Gooseneck Flatbed (Best All-Around Hauler)

For one trailer that handles the widest range of backhoe sizes and hauling scenarios, the MAXX-D LDX10236 is the one to beat. It splits the difference between the compact 32-footer and the full-size 40-footer, giving you extra deck space without the turning radius penalties of a longer rig.

Key Specs

• Model: LDX Low-Pro Tandem Dual Flatbed

• Frame: Engineered I-Beam Frame with Torque Tube, 6" Channel Outer Frame

• Neck: Standard Height Engineered Neck

• Brakes: Electric Over Hydraulic Disc Brakes

• Coupler: 2-5/16" 30K Round Gooseneck Coupler

• Jacks: 2 x Hydraulic Jacks

• Ramps: MAXXD-OUT Ramps (Full Width Coverage)

• Dovetail: 5' Dovetail

• Winch: Winch Plate Included

• Storage: Front Tool Box in Neck

Length

The LDX10236 measures 36 feet long by 102 inches wide, with a low-pro tandem dual configuration that keeps your load sitting closer to the ground. That lower deck height reduces ramp angle when loading a backhoe, which means less scraping and a smoother transition from ground to deck. The hydraulic jacks let you raise and lower the trailer faster and with less effort than standard drop-leg jacks, which adds up on busy days with multiple hitches.

GVWR and Payload

The LDX10236 comes in at a GVWR of 25,990 lbs with a payload capacity of 16,215 lbs. The included winch plate lets you add a recovery winch for machines that can't drive on under their own power or need precise positioning on the deck.

3. MAXX-D LKX10240 40' Low-Pro Gooseneck (Best for Larger Backhoes)

The MAXX-D LKX10240 is the heavy hitter of this lineup, built for operators who regularly haul larger backhoes or need maximum deck space for machines with wide stances or long tail swings. At 40 feet, this trailer gives you room to breathe.

Key Specs

• Model: LKX Low-Pro Tandem Dual Flatbed

• Dimensions: 102" Wide x 40' Long (35' Flat + 5' Dovetail)

• Empty Weight: 9,310 lbs

• Coupler: 2-5/16" 30K Round Gooseneck Coupler

• Jacks: 2 x 10K Drop-Leg Jacks

• Ramps: MAXXD-OUT Ramps with 5' Dovetail

• Winch: WARRIOR 18K Winch in Neck

• Hydraulics: Hydraulic Upgrade Package with Wireless Remote

• Suspension: Slipper Spring Suspension

• Tires: Dual ST235/80R16 E Tires (9 total)

• Storage: Engineered Neck with Front Toolbox, 48" Side Mount Toolbox, Hot Shot Riser Box/Chain Rack

Length

The 40-foot deck, 35 feet of flat plus a 5-foot dovetail, gives larger backhoes the room they need to sit properly centered over the axles. Proper weight distribution directly affects tire wear, trailer tracking, and braking performance. The extra length earns its keep on every haul.

GVWR and Payload

The LKX10240 is rated at a GVWR of 25,000 lbs with a payload of 15,690 lbs. The WARRIOR 18K Winch built into the neck lets you load partially disabled machines without a separate recovery vehicle on site. The hydraulic upgrade package with wireless remote lets you control jacks and hydraulic functions from outside the cab, which improves safety and efficiency when working solo or in tight spaces.

Find the right gooseneck trailer for loading your backhoe.

How Do All Three MAXX-D Gooseneck Trailers Compare?

The Best Gooseneck Trailers Are Available at Poplar Bluff Trailer

Poplar Bluff Trailer stocks gooseneck trailers from top brands like MAXX-D and Load Trail.

All three MAXX-D trailers cover a real range of hauling needs without cutting corners on specs. The 32-footer keeps things manageable on tight job sites, the 36-footer handles the widest variety of machines, and the 40-footer gives larger backhoes the room and stability they need.

We stock all three at Poplar Bluff Trailer, and our inventory updates daily so you know exactly what's available before you make the trip. Our team works specifically with heavy equipment buyers and can help you match the right trailer to your machine, your truck, and how you haul.

View Poplar Bluff Trailer's full inventory.

Frequently Asked Questions (FAQs)

What GVWR Do I Need to Haul a Standard Backhoe?

Most standard backhoes weigh between 14,000 and 18,000 lbs depending on configuration and attachments, so you need a trailer with a minimum GVWR of 25,000 lbs. That rating gives you a working payload of roughly 15,000 to 16,000 lbs after accounting for trailer weight, which keeps you legal with a small safety margin. Never load a trailer at or above its maximum rated payload; that's how axles fail and tires blow.

Can a Half-Ton Truck Pull a Gooseneck Trailer With a Backhoe?

No. Trailers in the 25K GVWR range require a three-quarter ton or one-ton truck at minimum, and most operators hauling backhoes run a one-ton dually like a Ford F-450, RAM 3500, or Chevrolet Silverado 3500HD. Always cross-reference your truck's rated gooseneck towing capacity against the trailer's total loaded weight before you hook up.

What Is the Difference Between Electric Brakes and Electric Over Hydraulic Brakes?

Electric brakes use a signal from the tow vehicle's brake controller to activate a magnet inside each brake drum, but their stopping power drops under heavy loads and gets inconsistent in wet or muddy conditions. Electric Over Hydraulic (EOH) brakes use that same signal to trigger a hydraulic actuator, applying the brakes with significantly more force and consistency across all axles.

The LDB10232 and LDX10236 run EOH disc brake systems, while the LKX10240 uses electric brake axles. Both setups are designed to stop 15,000+ lbs of loaded trailer on a public road.

How Long Should a Gooseneck Trailer Be for a Backhoe?

For most standard backhoes, 32 feet is the practical minimum; you need enough flat deck to position the machine so its weight sits properly over the axles, or you risk overloading the truck's rear axle or creating trailer sway. A 36-foot trailer adds flexibility for different backhoe sizes or carrying a second piece of equipment, and the extra four feet disappears fast with a machine that has a long rear overhang. For larger backhoes in the 18,000 lb class or machines with a wide stance, a 40-footer like the MAXX-D LKX10240 gives you maximum positioning flexibility and a stable ride under heavy loads.

Where Is Poplar Bluff Trailer Located?

Poplar Bluff Trailer is in Poplar Bluff, Missouri, serving operators across Missouri, Arkansas, Kentucky, and Tennessee, including the surrounding mid-South region. We stock the full MAXX-D gooseneck lineup, including all three trailers covered here, though inventory moves fast so it's worth checking our site or calling ahead before making the trip. Our staff works specifically with heavy equipment buyers and can help you match the right trailer to your machine, your truck, and your hauling situation.

*Note: Prices shown are estimates based on current market conditions at the time of writing and may change without notice. Confirm trailer availability, specifications, and final pricing directly with Poplar Bluff Trailer.
